1.- Manual test:

1) A short press (>1s) on the button initiates a function test lasting 5 seconds (battery capacity must be greater than 5% = charging 30 minutes).

2) Holding down the button (>10s) resets the timer (System Reset).

2.- Functional test:

The 5-second functional test, performed every 7 days, serves to check the functionality of the emergency unit, batteries and LED module. If a main power failure occurs while a bump test is being performed, the test will be postponed and the system will go into emergency operation.

3.- Autonomy Test (Automatic):

(2 hours): The test shall be performed exactly 16 hours after initial installation. The test shall be conducted every 180-182 days. 2 hour duration test in the first 180-182 days to verify battery capacity. 1.5 hour duration test is performed in the next 180-182 days and annually to verify the capacity of the batteries. A life test should only be initiated when the battery supply is fully charged. If a main supply failure occurs during a life test, the test will be postponed and the system will go into emergency operation. The indicator will flash green within 5 days if the endurance test was successful.

4.- Display of the test results: The system status is displayed locally by means of a two-colour LED indicator:

- Permanent green: Standby, System OK.

- Fast flashing green (0.25s on - 0.25s off): Functional test in progress.

- Slow flashing green (1s on - 1s off): Duration test in progress.

- Steady red: Lamp failure.

- Fast flashing red (0.25s on - 0.25s off): Battery capacity failure.

- Slow flashing red (1s on - 1s off): Battery failure.

- Green and red off: Battery operation.

Fault status: If an error is detected, the indicator LED will change to red. If the error has been corrected, reconnect the battery after switching off the main power.

Battery life test failure: After a battery change, press and hold the button (>10s) to reset the timer.
