EN-60598-1
EN-60598-2-22
EN-62034
Installation type:
· Electrical rail: Compatible with ONETRACK UL 3 circuits
Compatible with EUROSTANDARD tracks
The luminaire has a built·in button, which allows:
· Simulation test of supply failure.
Remote control input that allows:
· Standby without sopwer supply.
· Resumed in emergency status without power supply.
· Switched on in emergency status (more than 24 h of charge)
· Manual and remote duration test. (more than 24 hours of charge).
· Date and time programming of the tests.
· Reset of the luminaire status.
| H | A | B |
|---|---|---|
| 2 m | 7,5 m | 17,7 m |
| 2,5 m | 8,3 m | 20,5 m |
| 3 m | 8,8 m | 22,7 m |
| 4 m | 3,9 m | 20,2 m |
| 5 m | - | 12,8 m |
Spacing data calculated with no reflections and a maintenance factor of 0.9.
Compliant with the updated standard EN-1838:2024.
Minimum illuminance of 1 lux over a 1 m wide evacuation path.
The calculation of spacing distances is carried out considering the height of the light emission point, without taking into account the dimensions of the luminaire.
| H | A | B | C | D |
|---|---|---|---|---|
| 2 m | 3,3 m | 6,5 m | 3,3 m | 6,5 m |
| 2,5 m | 3,9 m | 7,5 m | 3,9 m | 7,5 m |
| 3 m | 4,5 m | 8,5 m | 4,5 m | 8,5 m |
| 4 m | 5,1 m | 10,0 m | 5,1 m | 10,5 m |
| 5 m | 5,7 m | 11,5 m | 5,7 m | 11,5 m |
Spacing data calculated with no reflections and a maintenance factor of 0.9.
Compliant with the updated standard EN-1838:2024.
Minimum illuminance of 0.5 (anti-panic calculation).
The calculation of spacing distances is carried out considering the height of the light emission point, without taking into account the dimensions of the luminaire.
Product weight: 0.26 kg
Boxed product weight: 0.32 kg
Weight of box of 12 units: 3.99 kg
No hay información BC3 disponible
| Battery system | Control system | Emergency | Mains | Type* | Lens | Duration | Battery | Colour | Warranty | Certifications | Part number |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Self-contained | AutoTest | 235 lm | 140 lm | M/NM | Anti-panic and Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSP6255LXPN |
| Self-contained | AutoTest | 250 lm | 150 lm | M/NM | Anti-panic and Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSP6255LXP |
| Self-contained | AutoTest | 155 lm | 95 lm | M/NM | Anti-panic and Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSP6175LXP3N |
| Self-contained | AutoTest | 165 lm | 100 lm | M/NM | Anti-panic and Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSP6175LXP3 |
| Self-contained | DALI2 | 235 lm | 140 lm | M/NM | Anti-panic and Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSP6255LAPN |
| Self-contained | DALI2 | 250 lm | 150 lm | M/NM | Anti-panic and Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSP6255LAP |
| Self-contained | DALI2 | 155 lm | 95 lm | M/NM | Anti-panic and Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSP6175LAP3N |
| Self-contained | DALI2 | 165 lm | 100 lm | M/NM | Anti-panic and Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSP6175LAP3 |
| Self-contained | Wireless SmartZ® | 235 lm | 140 lm | M/NM | Anti-panic and Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSP6255LWPN |
| Self-contained | Wireless SmartZ® | 250 lm | 150 lm | M/NM | Anti-panic and Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSP6255LWP |
| Self-contained | Wireless SmartZ® | 155 lm | 95 lm | M/NM | Anti-panic and Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSP6175LWP3N |
| Self-contained | Wireless SmartZ® | 165 lm | 100 lm | M/NM | Anti-panic and Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSP6175LWP3 |
