EN-60598-1
EN-60598-2-22
Luminaire made up of a spotlight + electrical equipment with batteries
Installation type:
· Recessed ceiling.
Double spring clips installation method.
Luminaire of the type: Centralized.
Valid to be supply in the following ways:
· Directly at rated voltage.
· By means of a centralized power supply unit at the nominal voltage (consult possible options).
| H | A | B |
|---|---|---|
| 2 m | 7,7 m | 18,7 m |
| 2,5 m | 7,6 m | 21,0 m |
| 3 m | 4,7 m | 20,3 m |
| 4 m | 1,9 m | 18,3 m |
| 5 m | - | 11,3 m |
Spacing data calculated with no reflections and a maintenance factor of 0.9.
Compliant with the updated standard EN-1838:2024.
Minimum illuminance of 1 lux over a 1 m wide evacuation path.
The calculation of spacing distances is carried out considering the height of the light emission point, without taking into account the dimensions of the luminaire.
Product weight: 0.23 kg
Boxed product weight: 0.29 kg
Weight of box of 18 units: 5.52 kg
No hay información BC3 disponible
| Battery system | Control system | Emergency | Mains | Type* | Lens | Duration | Battery | Colour | Warranty | Certifications | Part number |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Self-contained | AutoTest | 235 lm | NM | Antipanic | 1 h | 3.2V-1.5Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR3250LXN | |
| Self-contained | AutoTest | 235 lm | NM | Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR3251LXN | |
| Self-contained | AutoTest | 280 lm | NM | Antipanic | 1 h | 3.2V-1.5Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSR3250LX | |
| Self-contained | AutoTest | 280 lm | NM | Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSR3251LX | |
| Self-contained | AutoTest | 140 lm | NM | Antipanic | 3 h | 3.2V-1.8Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR3170LX3N | |
| Self-contained | AutoTest | 140 lm | NM | Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR3171LX3N | |
| Self-contained | AutoTest | 165 lm | NM | Antipanic | 3 h | 3.2V-1.8Ah LiFePO₄ | White | 5 Years | CE UK CMIM Civil Defense | LSR3170LX3 | |
| Self-contained | AutoTest | 165 lm | NM | Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | White | 5 Years | CE UK CMIM Civil Defense | LSR3171LX3 | |
| Self-contained | DALI2 | 235 lm | 140 lm | M/NM | Antipanic | 1 h | 3.2V-1.5Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR9250LAPN |
| Self-contained | DALI2 | 235 lm | 140 lm | M/NM | Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR9251LAPN |
| Self-contained | DALI2 | 280 lm | 170 lm | M/NM | Antipanic | 1 h | 3.2V-1.5Ah LiFePO₄ | White | 5 Years | CE UK CMIM Aenor N ENEC IECEE | LSR9250LAP |
| Self-contained | DALI2 | 280 lm | 170 lm | M/NM | Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | White | 5 Years | CE UK CMIM Aenor N ENEC IECEE | LSR9251LAP |
| Self-contained | DALI2 | 140 lm | 85 lm | M/NM | Antipanic | 3 h | 3.2V-1.8Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR9170LAP3N |
| Self-contained | DALI2 | 140 lm | 85 lm | M/NM | Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR9171LAP3N |
| Self-contained | DALI2 | 165 lm | 100 lm | M/NM | Antipanic | 3 h | 3.2V-1.8Ah LiFePO₄ | White | 5 Years | CE UK CMIM Aenor N ENEC IECEE Civil Defense | LSR9170LAP3 |
| Self-contained | DALI2 | 165 lm | 100 lm | M/NM | Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | White | 5 Years | CE UK CMIM Aenor N ENEC IECEE Civil Defense | LSR9171LAP3 |
| Self-contained | Wireless SmartZ® | 235 lm | 140 lm | M/NM | Antipanic | 1 h | 3.2V-1.5Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR9250LWPN |
| Self-contained | Wireless SmartZ® | 235 lm | 140 lm | M/NM | Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR9251LWPN |
| Self-contained | Wireless SmartZ® | 280 lm | 170 lm | M/NM | Antipanic | 1 h | 3.2V-1.5Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSR9250LWP |
| Self-contained | Wireless SmartZ® | 280 lm | 170 lm | M/NM | Escape Route | 1 h | 3.2V-1.5Ah LiFePO₄ | White | 5 Years | CE UK CMIM | LSR9251LWP |
| Self-contained | Wireless SmartZ® | 140 lm | 85 lm | M/NM | Antipanic | 3 h | 3.2V-1.8Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR9170LWP3N |
| Self-contained | Wireless SmartZ® | 140 lm | 85 lm | M/NM | Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | Black | 5 Years | CE UK CMIM | LSR9171LWP3N |
| Self-contained | Wireless SmartZ® | 165 lm | 100 lm | M/NM | Antipanic | 3 h | 3.2V-1.8Ah LiFePO₄ | White | 5 Years | CE UK CMIM Civil Defense | LSR9170LWP3 |
| Self-contained | Wireless SmartZ® | 165 lm | 100 lm | M/NM | Escape Route | 3 h | 3.2V-1.8Ah LiFePO₄ | White | 5 Years | CE UK CMIM Civil Defense | LSR9171LWP3 |
| Central Battery System (CBS) | 170 lm | 170 lm | Antipanic | - | N/A | Black | 2 Years | CE UK CMIM | LSR318023N | ||
| Central Battery System (CBS) | 170 lm | 170 lm | Antipanic | - | N/A | Black | 2 Years | CE UK CMIM | LSR320024N | ||
| Central Battery System (CBS) | 170 lm | 170 lm | Escape Route | - | N/A | Black | 2 Years | CE UK CMIM | LSR318123N | ||
| Central Battery System (CBS) | 170 lm | 170 lm | Escape Route | - | N/A | Black | 2 Years | CE UK CMIM | LSR320124N | ||
| Central Battery System (CBS) | 200 lm | 200 lm | Antipanic | - | N/A | White | 2 Years | CE UK CMIM | LSR318023 | ||
| Central Battery System (CBS) | 200 lm | 200 lm | Antipanic | - | N/A | White | 2 Years | CE UK CMIM | LSR320024 | ||
| Central Battery System (CBS) | 200 lm | 200 lm | Escape Route | - | N/A | White | 2 Years | CE UK CMIM | LSR318123 | ||
| Central Battery System (CBS) | 200 lm | 200 lm | Escape Route | - | N/A | White | 2 Years | CE UK CMIM | LSR320124 |
