SPAZIO ON 10
SPECIFICATION
- Polycarbonate body
- Escape route lens
Anti-panic lens
Asymmetrical wall lens - IP42
- IK04
- 95 lm – 250 lm
- Duration: 1 – 3 h · Battery: LiFePO4
- Charging time: 12 h
- Supply: 230 V – 50 Hz
- LED temperature: 4000 ºK
- Working temperature: 0 ºC to +40 ºC
- DALI-2
- Wireless SmartZ®
- Warranty 5 year AutoTest, Wireless SmartZ® & DALI-2 Lithium
- EVO10 Warranty 10 year
Downloads:
Download Declaration of Conformity
Available with:LiFePO4 Technology
Technical information
DALI-2
| Emergency | Type* | Dur. | Battery | Ref. |
| 250 lm | NM | 1 h | 3.2V 1.5A/h LiFePO₄ | LSMX3250LA |
| 250 lm | NM | 1 h | 3.2V 1.5A/h LiFePO₄ | LSMX3251LA |
| 250 lm | NM | 1 h | 3.2V 1.5A/h LiFePO₄ | LSMX3252LA |
| 95 lm | NM | 3 h | 3.2V 1.5A/h LiFePO₄ | LSMX3100LA3 |
| 95 lm | NM | 3 h | 3.2V 1.8A/h LiFePO₄ | LSMX3101LA3 |
| 95 lm | NM | 3 h | 3.2V 1.8A/h LiFePO₄ | LSMX3102LA3 |
Wireless SmartZ®
| Emergency | Type* | Dur. | Battery | Ref. |
| 250 lm | NM | 1 h | 3.2V 1.5A/h LiFePO₄ | LSMX3250LW |
| 250 lm | NM | 1 h | 3.2V 1.5A/h LiFePO₄ | LSMX3251LW |
| 250 lm | NM | 1 h | 3.2V 1.5A/h LiFePO₄ | LSMX3252LW |
| 95 lm | NM | 3 h | 3.2V 1.8A/h LiFePO₄ | LSMX3100LW3 |
| 95 lm | NM | 3 h | 3.2V 1.8A/h LiFePO₄ | LSMX3101LW3 |
| 95 lm | NM | 3 h | 3.2V 1.8A/h LiFePO₄ | LSMX3102LW3 |
*NM: Non Maintained. The luminaire operates from emergency supply only upon failure of the normal mains supply.
Luminous flux decreases by 6% in black colour version.
For black version, include “N” at the end of the part number.
More information about our systems: AutoTest y Wireless
DALI-2
| Ref. | Tech Sheet | Photometry | Installation guide |
| LSMX3250LA | Tech Sheet | LDT | Guide |
| LSMX3251LA | Tech Sheet | LDT | Guide |
| LSMX3252LA | Tech Sheet | LDT | Guide |
| LSMX3100LA3 | Tech Sheet | LDT | Guide |
| LSMX3101LA3 | Tech Sheet | LDT | Guide |
| LSMX3102LA3 | Tech Sheet | LDT | Guide |
Wireless SmartZ®
| Ref. | Tech Sheet | Photometry | Installation guide |
| LSMX3250LW | Tech Sheet | LDT | Guide |
| LSMX3251LW | Tech Sheet | LDT | Guide |
| LSMX3252LW | Tech Sheet | LDT | Guide |
| LSMX3100LW3 | Tech Sheet | LDT | Guide |
| LSMX3101LW3 | Tech Sheet | LDT | Guide |
| LSMX3102LW3 | Tech Sheet | LDT | Guide |
Download installation manual, electrical connection / test and instructions for use:
Spazio ON
- EN-60598-2-22
- AutoTest: EN-62034
-
DALI-2: EN 62386
-
Wireless SmartZ®: ETSI EN 303 447-1
